Product Description
The RPS Studio 3-in-1 transciever is a very versatile wireless trigger
that can be used to:
• Release the shutter of a digital camera up to 300 feet away
• Fire a studio flash such as a monolite
• Fire a shoe mount speedlite up to 100 feet away.
• Features 16 channels
The receiver mounts conveniently on the accessory shoe of the camera. Just plug the
supplied cord into the receiver and into the camera remote release
socket. Set the transmitter nd receiver to the camera mode. In
camera mode, the transmitter has a two position switch. The first
position activates the auto focus and exposure. The second position
triggers the shutter. The transmitter can now be used to
release the shutter on the camera up to 300 feet away. 16 channels are
provided.
Wireless Flash Release for Speedlites
The transmitter has a hot shoe to make mounting on the camera easy and
secure. In flash mode, the hot shoe fires the transmitter. If the
camera does not have a hot shoe, a PC cord is supplied. The test button
on the transmtter can also be used to fire the flash. Both the
transmitter and the receiver have locking shoes.
The receiver can mount to an accessory shoe, a light stand or a tripod and features a
hot shoe to accept speedlites. If the speedlite does not have a hot
shoe, a PC outlet is included. Use the cord that comes with the
speedlite.
Wireless Flash Release for Monolites
To use for a monolite, simply attach the transmitter to the hot shoe of the
camera, as above, and set both the transmitter and receiver in the flash
mode.
There is a 3.5mm cord and a 1/4” plug adapter included for monolites. Simply
use the appropriate cord and adapter for your monolite. We have also
included an accessory shoe to allow you to mount the receiver on the
monolite. the shoe comes with sticky back to affix to the monolite. This
prevents the receiver from just hanging from the back of your monolite.
The range for wireless flash is about 100 feet. Additional
receivers are available.
Also available are additional camera cords If you change cameras in the
future, simply order the appropriate camera cord. These are listed as
the RS-RMC series cords.
The transmitter is supplied with a 12v #23 battery. The receiver uses 2
AAA bateries, not included.
